CSInterfacer exchanges data among HSPF12, MOUSE, SWMM4/5, plain text, and WASP5


Command line formats
CSInterfacer HSPF commandfile.txt interfacefile.int
CSInterfacer M11E nodefile.txt m11.in
CSInterfacer MOUS flowfile.txt interfacefile.int
CSInterfacer POLL commandfile.txt interfacefile.int
CSInterfacer SPLT commandfile.txt interfacefile.int
CSInterfacer SQSH interfacefile.int interfacefile.int
CSInterfacer SW54 flowfile.txt interfacefile.int
CSInterfacer SWM5 swmmout.out flowfile.txt
CSInterfacer TEXT flowfile.txt interfacefile.int
CSInterfacer WASP interfacefile.int waspname

Functionality
HSPF - Convert HSPF plot file to SWMM 4 interface, SWMM 5 interface, or SWMM 5 timeseries. Commandfile contains pollutant information and multiple filenames
M11E - Edit flags in an M11.in file based on list in Myfile.txt. M11.in file is overwritten
MOUS - Convert Mouse text output generated using M11Extra to SWMM 4 interface
POLL - Add pollutants to SWMM 4 interface. Commandfile contains pollutant information and a single SWMM interface filename
SPLT - Apportion flows from select locations into multiple locations in a SWMM 4 interface file
SQSH - Sum flows and loads at matching locations within a SWMM 4 interface file
SW54 - Convert SWMM 5 OUTFLOW text to SWMM4 interface flow file
SWM5 - Convert SWMM 5 binary output to NetSTORM-compatible data file (flows only)
TEXT - Convert text to SWMM 4 interface flow file. Command/datafile contains location IDs [Locations] and date/flow data [Flows] mm-dd-yyyy hh:mm q1 ... qn
WASP - Convert SWMM 4 interface to WASP non-point source (.nps). .nps extension added by program

Written by Mitch Heineman, CDM Smith, Cambridge, Massachusetts, 2004-2012
